Velab VE-M6 Biological Monocular Microscope (Advanced), WF 10x/18 mm with Block Screw Eyepiece

Specifications

• Eyepiece: Wf 10X/18 mm with Block Screw.
• Head: Monocular Head, 45 degree Inclined, 360 degree Rotatable.
• Nosepiece: Quadruple Nosepiece with Anti-Slip Grip and Click-Stops.
• Objectives: 4X, 10X, 40X (S) and 100X (S) (Oil), Achromatic Optics, Anti-Slip Grip and Color Ring for Easy Identification.
• Stand: Stative, Robust and Reinforced with Epoxy Paint Finish.
• Stage: Two-Layer Stage with X-Y Coaxial Movement, 125 x 125 mm / 4.92" x 4.92", Vernier, Millimeter Scale, Clamp and Height Adjustment with Stop
• Condenser: Abbe, N.A. 1.25 with Height Adjustment Screw.
• Diaphragm: Iris Type with Filter Holder.
• Focusing: Coarse and Fine Anti-Slip Control Knob with Tension Adjustment.
• Illumination: Led with Variable Intensity Control.
• Weight: 11.52 lb / 5.22Kg
• Dimensions: 9.06" x 14.57" x 18.5" / 230 x 370 x 469 mm
• Power Supply: 110-240V, 50/60 Hz Ac Adapter.

Accesories Included

• Blue Filter.
• Dust Cover.
• Immersion Oil.
• Power Cord.

Warranty

• 10-Years Limited Warranty.

Documents

• Data Sheet
