| Volume range (H2O) | 0.001 - 0.1 l |
| Stator diameter | 10 mm |
| Rotor diameter | 7.5 mm |
| Gap between rotor and stator | 0.35 mm |
| allowable Speed max. | 25000 rpm |
| Circumferential speed max. | 9.8 m/s |
| Immersion depth | 22 - 85 mm |
| Shaft length | 105 mm |
| Material in contact with medium | PTFE, AISI 316L |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Suitable for abrasive substances | yes |
| Working temperature max. | 180 ðC |
| Sterilization methods | all methods |
| Ultimate fineness, suspensions | 10 - 50 õm |
| Ultimate fineness, emulsions | 1 - 10 õm |
| Weight | 0.392 kg |
Data Sheet
Manual S25N_8G_10G_ST
