| Stator diameter | 25 mm |
| Rotor diameter | 17 mm |
| Gap between rotor and stator | 0.5 mm |
| allowable Speed max. | 25000 rpm |
| Circumferential speed max. | 22.2 m/s |
| Immersion depth | 40 - 85 mm |
| Shaft length | 110 mm |
| Material in contact with medium | FFPM, SIC, AISI 316L, AISI 302 |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Working temperature max. | 220 ðC |
| Sterilization methods | all methods |
| Vacuum | 1 mbar |
| Pressure max. | 6 bar |
| Ultimate fineness, suspensions | 15 - 50 õm |
| Ultimate fineness, emulsions | 1 - 10 õm |
Data Sheet
Manual S25KV25_FIL_GIL
