Estimated Delivery
Jun 06 - Jun 13
Couldn't load pickup availability
Free standard shipping on orders over $50
| Motion | Orbital, 25 mm |
| Capacity | 50 lb (22.7kg) @ 125 rpm, 10 lb (4.53kg) @ 500 rpm |
| Temp. Range | 15°C below Ambient – 65°C |
| Uniformity | ± 0.5°C at 37°C |
| Speed Range | 15 rpm – 500 rpm |
| Tray Size (Length) | 457 mm (18 in) |
| Timer | 1 second – 160 hours |
| Tray Size (Width) | 457 mm (18 in) |
| Speed Accuracy | Above 100rpm +/- 1%, Below 100rpm /- 1 rpm |
| Tray Construction | Aluminum |
| Control | Digital |
| Dimensions (Length) | 815 mm (32.1 in) |
| Dimensions (Width) | 675 mm (26.6 in) |
| Dimensions (Height) | 596 mm (23.5 in) |
| Calibration | Temperature calibration |
| Communication | RS232 |
| Drive System | Triple Eccentric; Brushless DC Motor |
| Inner Dimensions (Width) | 629 mm (24.8 in) |
| Inner Dimensions (Length) | 523 mm (20.6 in) |
| Inner Dimensions (Height) | 432 mm (17 in) |
| Net Weight | 131.7 kg (290.41 lb) |
| Power | 120V, 10A, 50/60Hz |
| Power Consumption | 800 W |
| Safety Certification | TUV |
| Speed Range | 15 rpm – 500 rpm |
| Working Environment | 59°F – 90°F, 80%RH, non-condensing |
| Working Environment | 15°C – 32°C, 80%RH, non-condensing |
