| Spindle geometry | Cylinder |
| Connection | Thread M2.5 LH |
| Hook connector | yes |
| Sample volume | 6.7 ml |
| Flow Jacket | yes |
| Mounting Bracket | yes |
| Sample container: | Specified chamber |
| Working temperature max. | 100 ðC |
| Viscosity Accuracy (FSR) | 2 % |
| Viscosity Repeatibility (FSR) | 0.2 % |
| Min. FSR match ROTAVISC lo-vi | 1.5 mPa.s |
| Max. FSR match ROTAVISC lo-vi | 30000 mPa.s |
| Min. FSR match ROTAVISC me-vi | 16 mPa.s |
| Max. FSR match ROTAVISC me-vi | 320000 mPa.s |
| Min. FSR match ROTAVISC hi-vi I | 32 mPa.s |
| Max. FSR match ROTAVISC hi-vi I | 640000 mPa.s |
| Min. FSR match ROTAVISC hi-vi II | 128 mPa.s |
| Max. FSR match ROTAVISC hi-vi II | 2600000 mPa.s |
| Material in contact with medium | stainless steel 1.4404 |
| Dimensions (W x H x D) | 300 x 110 x 275 mm |
| Weight | 1.656 kg |
Data Sheet
Manual VOLS-1 (EN)
