| Volume | 2 l |
| Fill level diameter ratio | 1.22 |
| Fill level at nominal volume | 123 mm |
| Vessel inner diameter | 150 mm |
| Vessel outer diameter | 190 mm |
| Height (room dimension) | 290 mm |
| Width (room dimension) | 243 mm |
| Depth (room dimension) | 195 mm |
| Flange type | acc. DIN 12214 with circular groove |
| Flange dimension | DN150 |
| Flange collar diameter | 159 mm |
| Bottom shape | Torispherical head |
| Tempering jacket filling capacity | 1 L |
| Tempering jacket inlet connection | DN 15 (tech-flange) |
| Tempering jacket inlet inner diameter | 15 mm |
| Vacuum application | yes |
| Tempering jacket outlet connection | DN 15 (tech-flange) |
| Tempering jacket oulet inner diameter | 15 mm |
| Thread closure system | M16x1 |
| Width across flats | WAF 22 |
| Material closure system | stainless steel 1.4404 |
| Reactor vessel material | borosilicate glass 3.3 DIN ISO 3585 |
| Working temperature | -50 - 230 ðC |
| Useable volume | 120 - 2300 ml |
| Useable volume with temperature probe min. | 400 ml |
| Pressure max. | atmospheric pressure |
| Attainable vacuum | 3 mbar |
| Material in contact with medium | borosilicate glass 3.3 DIN ISO 3585 |
Data Sheet
