| Spindle geometry | Disc |
| Connection | Thread M2.5 LH |
| Quick plug connector | yes |
| Hook connector | yes |
| Diameter | 18.7 mm |
| Immersion depth | 50 mm |
| Spindle length | 115 mm |
| Mounting Bracket | yes |
| Sample container: | 600mL beaker low |
| Viscosity Accuracy (FSR) | 1 % |
| Viscosity Repeatibility (FSR) | 0.2 % |
| Min. FSR match ROTAVISC lo-vi | 150.0 mPa.s |
| Max. FSR match ROTAVISC lo-vi | 29994 mPa.s |
| Min. FSR match ROTAVISC me-vi | 1600.0 mPa.s |
| Max. FSR match ROTAVISC me-vi | 320000 mPa.s |
| Min. FSR match ROTAVISC hi-vi I | 3200.0 mPa.s |
| Max. FSR match ROTAVISC hi-vi I | 640000 mPa.s |
| Min. FSR match ROTAVISC hi-vi II | 12800 mPa.s |
| Max. FSR match ROTAVISC hi-vi II | 2560000 mPa.s |
| Material in contact with medium | stainless steel 1.4404 |
| Dimensions (W x H x D) | 20 x 117 x 20 mm |
| Weight | 0.024 kg |
Data Sheet
Technical info_SP-2
