Estimated Delivery
May 30 - Jun 06
Couldn't load pickup availability
Free standard shipping on orders over $50
| Volume range (H2O) | 0.01 - 1.5 l |
| Stator diameter | 18 mm |
| Rotor diameter | 12.7 mm |
| Gap between rotor and stator | 0.25 mm |
| allowable Speed max. | 25000 rpm |
| Circumferential speed max. | 16.6 m/s |
| Immersion depth | 40 - 225 mm |
| Shaft length | 270 mm |
| Material in contact with medium | FFPM, SIC, AISI 316L, AISI 302 |
| pH range | 2 - 13 |
| Suitable for solvents | yes |
| Working temperature max. | 220 ðC |
| Sterilization methods | all methods |
| Vacuum | 1 mbar |
| Pressure max. | 6 bar |
| Ultimate fineness, suspensions | 10 - 50 õm |
| Ultimate fineness, emulsions | 1 - 10 õm |
| FDA conformity | yes |
| Weight | 0.5514 kg |
Data Sheet
Manual S25KV_18G_25G_25F
