| OIML Class | III |
| Maximum quantity of divisions from converter | 838 860 ×10 |
| Maximum quantity of verification units | 6000 e |
| Minimum volatge per verification unit | 0.4 µV |
| Maximum voltage per verification unit | 3.25 µV |
| Minimum load cell impedance | 50 Ω |
| Maximum load cell impedance | 1200 Ω |
| Load cell excitation voltage | 5V DC |
| Maximum increase of signal | 39 mV |
| Connection of load cells | 4 or 6 wires + shield |
| Display | 4.3” LCD (backlit) |
| Device dimensions W x D x H | 181×136×60 mm |
| Packaging dimensions W x D x H | 220×190×90 mm |
| Net weight | 0.6 kg |
| Gross weight | 0.78 kg |
| Protection class | IP 43 |
| Keypad | microswitch |
| Housing | ABS plastic |
| Communication interface | RS232 |
| Optional interfaces | RS232 |
| Power supply | 100 – 240 V AC 50/60 Hz |
| Power consumption max. | 5 W |
| Optional power supply | 12 V DC and battery |
| Operation time on batteries | max 7h |
| Power supply | detachable adapter, battery NiMH 6×AA |
| Number of buttons | 5 |
| Multiple range | 1 or 2 ranges |
| Additional LCD display | WD-4/8 (option) |
| Operating temperature | -10 – +40 °C |
| Storage temperature | -10 – +50 °C |
| Relative humidity | 10% – 80% RH no condensation |
