| Input voltage | max. 70 V DC / 49 V AC |
|---|---|
| Output voltage | 3 x 45 Vrms |
| Output current | 10 Aeff / 15 Amax (5s) |
| Nominal output power | 600 VA / 900 VAmax (5s) |
| Output frequency | max. 4,000 Hz |
| Modulation | typePulse amplitude modulation (PAM) |
| Brake resistor (internal) | 60 W |
| Ambient temperature | 5 – 40 °C |
| Protection category | IP 20 |
| Design | Switch cabinet installation |
| EMV | EN 61800-3 |
| Weight | 2.6 kg |
| Power supply module | e@syDrive 4428 |
| Display | 2 x LED |
| Configuration | Via USB using the “SycoDrive” user interface Via micro SD card |
| Interfaces | 7 x digital input (configurable) 1 x frequency output 1 x analog input 1 x analog output 2 x relay switching output (configurable) 2 x STO (safe torque off) 1 x CANopen 1 x RS232 |
| DC Spindle recommendation | 4025 DC (all types), 4033 DC* (all types), 4036 DC-T* (all types), 4040 DC-S, 4041 DC-S |
| AC Spindle recommendation | 4033 AC (all types), 4040 AC, 4041 AC (all types) |
| Special features | – STO (Safe Torque Off) – user interface for PC and Android tablet |
| * | reduced power |
DS_easyDrive_4625_2.002.1054_2025-01.pdf–\t161.66 KB
KA_4624-4625-4626_DE_2025-02.pdf–\t1.20 MB
KA_4624-4625-4626_EN_2025-02.pdf–\t1.17 MB
GA_4624-4625-4626_DE_2025-02.pdf–\t1.55 MB
GA_4624-4625-4626_EN_2025-02.pdf–\t1.58 MB
GA_CANopen_Objektbeschreibung_DE_2025-02.pdf–\t1.03 MB
GA_CANopen_Objektbeschreibung_EN_2025-02.pdf–\t1.00 MB
GA_RS232_Schnittstelle_DE_2025-02.pdf–\t577.79 KB
GA_RS232_Schnittstelle_EN_2025-02.pdf–\t574.06 KB
GA_SycoDrive_Software_DE_2025-02.pdf–\t1.63 MB
GA_SycoDrive_Software_EN_2025-02.pdf–\t1.54 MB
easyDrive_4624_4625_4626_SycoDrive-v1.9.17-Setup.zip–\t16.17 MB
easyDrive_4624_4625_4626_SycoDrive_FW-4.5.8.zip–\t63.84 KB
CSA_Umrichter_462446254626.pdf–\t48.96 KB
